Monitoring Table Size in PostgreSQL

By Vonng In Article 954 words 5 min
VonngAuthor of PG Exporter and Pigsty, working on PostgreSQL infrastructure and monitoring.

This 2018 article explains physical storage for ordinary PostgreSQL tables.

Table Storage Layout

An ordinary table has its own storage and may also have a TOAST table:

  • Main table: stores row data, relkind='r'.
  • TOAST table: stores out-of-line values when needed, relkind='t'. Some tables have no TOAST table.

A table and each of its indexes are separate relations:

  • Main relation: stores tuples.
  • Index relation: stores index tuples.

Each relation may have four forks:

  • main: the relation’s main file, numbered 0

  • fsm: stores information about free space in the main fork, numbered 1

  • vm: stores information about visibility in the main fork, numbered 2

  • init: used for unlogged tables and indexes, numbered 3

Each fork is stored in one or more files. The default segment size is 1 GiB; it can be changed when PostgreSQL is built.

To account for a table’s storage, include these relations:

  • Main table’s main relation (single)
  • Main table’s indexes (multiple)
  • TOAST table’s main relation (single)
  • TOAST table’s index (single)

Include every fork that exists for each relation: main, fsm, vm, and init. The init fork applies to unlogged relations.

Getting Table’s Associated Relations

The following query lists relation OIDs. Forks share a relation OID; they do not have independent OIDs. The left join keeps tables that have no TOAST table:

select
  nsp.nspname,
  rel.relname,
  rel.relnamespace    as nspid,
  rel.oid             as relid,
  rel.reltoastrelid   as toastid,
  toastind.indexrelid as toastindexid,
  ind.indexes
from
  pg_namespace nsp
  join pg_class rel on nsp.oid = rel.relnamespace
  CROSS JOIN LATERAL (select array_agg(indexrelid) as indexes from pg_index where indrelid = rel.oid) ind
  LEFT JOIN LATERAL (select indexrelid from pg_index where indrelid = rel.reltoastrelid) toastind ON true
where nspname not in ('pg_catalog', 'information_schema') and rel.relkind = 'r';
 nspname |  relname   |  nspid  |  relid  | toastid | toastindexid |      indexes
---------+------------+---------+---------+---------+--------------+--------------------
 public  | aoi        | 4310872 | 4320271 | 4320274 |      4320276 | {4325606,4325605}
 public  | poi        | 4310872 | 4332324 | 4332327 |      4332329 | {4368886}

Statistical Functions

PostgreSQL provides size functions for each part:

Function Statistical Scope
pg_total_relation_size(oid) Entire relation, including table, indexes, TOAST, etc.
pg_indexes_size(oid) Space occupied by relation’s index portion
pg_table_size(oid) Table forks and TOAST, including the TOAST index; excludes the main table’s indexes
pg_relation_size(oid) Get size of a relation’s main file part (main fork)
pg_relation_size(oid, 'main') Get relation’s main fork size
pg_relation_size(oid, 'fsm') Get relation’s fsm fork size
pg_relation_size(oid, 'vm') Get relation’s vm fork size
pg_relation_size(oid, 'init') Get relation’s init fork size

For routine monitoring, group storage into table and index space. For ordinary tables, pg_table_size plus pg_indexes_size equals pg_total_relation_size.

The following identities describe the components; they are formulas, not a complete SQL query:

 pg_table_size(relid)
     = pg_relation_size(relid, 'main')
     + pg_relation_size(relid, 'fsm')
     + pg_relation_size(relid, 'vm')
     + pg_relation_size(relid, 'init')
     + COALESCE(pg_total_relation_size(reltoastrelid), 0)

 pg_indexes_size(relid)
     = (SELECT COALESCE(sum(pg_total_relation_size(indexrelid)), 0)
        FROM pg_index WHERE indrelid = relid)

A TOAST table has one index. Use pg_total_relation_size(reltoastrelid) to include both the TOAST table and its index.

SELECT
  oid,
  relname,
  relnamespace::RegNamespace::Text               as nspname,
  relkind                                        as relkind,
  reltuples                                      as tuples,
  relpages                                       as pages,
  pg_total_relation_size(oid)                    as size
  FROM pg_class
WHERE oid = ANY(array(SELECT 16418 as id -- main
UNION ALL SELECT indexrelid FROM pg_index WHERE indrelid = 16418 -- index
UNION ALL SELECT reltoastrelid FROM pg_class WHERE oid = 16418)); -- toast

Wrap the query in a table-returning function for reuse. Replace the example OID with a table in your database:

CREATE OR REPLACE FUNCTION pg_table_size_detail(relation RegClass)
  RETURNS TABLE(
    id      oid,
    pid     oid,
    relname name,
    nspname text,
    relkind "char",
    tuples  bigint,
    pages   integer,
    size    bigint
  )
AS $$
BEGIN
  RETURN QUERY
  SELECT
    rel.oid,
    relation::oid,
    rel.relname,
    rel.relnamespace :: RegNamespace :: Text as nspname,
    rel.relkind                              as relkind,
    rel.reltuples::bigint                    as tuples,
    rel.relpages                             as pages,
    pg_total_relation_size(rel.oid)          AS size
  FROM pg_class rel
  WHERE rel.oid = ANY (array(
      SELECT relation::oid AS id -- main
      UNION ALL SELECT indexrelid FROM pg_index WHERE indrelid = relation -- index
      UNION ALL SELECT reltoastrelid FROM pg_class WHERE oid = relation)); -- toast
END;
$$
LANGUAGE PlPgSQL;

SELECT * FROM pg_table_size_detail(16418);

Each row’s size includes that relation’s attached storage. The main table row already includes its indexes and TOAST, so do not sum this column. tuples and pages come from planner statistics and can lag behind current data.

Sample result from the original environment:

geo=# select * from  pg_table_size_detail(4325625);
   id    |   pid   |        relname        | nspname  | relkind |  tuples  |  pages  |    size
---------+---------+-----------------------+----------+---------+----------+---------+-------------
 4325628 | 4325625 | pg_toast_4325625      | pg_toast | t       |   154336 |   23012 |   192077824
 4419940 | 4325625 | idx_poi_adcode_btree  | gaode    | i       | 62685464 |  172058 |  1409499136
 4419941 | 4325625 | idx_poi_cate_id_btree | gaode    | i       | 62685464 |  172318 |  1411629056
 4419942 | 4325625 | idx_poi_lat_btree     | gaode    | i       | 62685464 |  172058 |  1409499136
 4419943 | 4325625 | idx_poi_lon_btree     | gaode    | i       | 62685464 |  172058 |  1409499136
 4419944 | 4325625 | idx_poi_name_btree    | gaode    | i       | 62685464 |  335624 |  2749431808
 4325625 | 4325625 | gaode_poi             | gaode    | r       | 62685464 | 2441923 | 33714962432
 4420005 | 4325625 | idx_poi_position_gist | gaode    | i       | 62685464 |  453374 |  3714039808
 4420044 | 4325625 | poi_position_geohash6 | gaode    | i       | 62685464 |  172058 |  1409499136

Example: Relation Size Details Summary

select
  nsp.nspname,
  rel.relname,
  rel.relnamespace    as nspid,
  rel.oid             as relid,
  rel.reltoastrelid   as toastid,
  toastind.indexrelid as toastindexid,
  pg_total_relation_size(rel.oid)  as size,
  pg_relation_size(rel.oid) + pg_relation_size(rel.oid,'fsm')
  + pg_relation_size(rel.oid,'vm')
  + pg_relation_size(rel.oid,'init') AS relsize,
  pg_indexes_size(rel.oid)         as indexsize,
  COALESCE(pg_total_relation_size(reltoastrelid), 0) AS toastsize,
  ind.indexids,
  ind.indexnames,
  ind.indexsizes
from pg_namespace nsp
  join pg_class rel on nsp.oid = rel.relnamespace
  LEFT JOIN LATERAL (select indexrelid from pg_index where indrelid = rel.reltoastrelid) toastind ON true
  CROSS JOIN LATERAL (select array_agg(indexrelid ORDER BY indexrelid) AS indexids,
                      array_agg(indexrelid::regclass ORDER BY indexrelid) AS indexnames,
                      array_agg(pg_total_relation_size(indexrelid) ORDER BY indexrelid) AS indexsizes
              from pg_index where indrelid = rel.oid) ind
where nspname not in ('pg_catalog', 'information_schema') and rel.relkind = 'r';
